CDI CD42-T1A - CD42-T1 AHP-SWX Specifications

22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 47 of 52
SPECIFICATIONS
CD42-T1AHP-SWX
For Transmi er: CD42-T1AHP
Pressure Range: 15–3,000 psi [1–207 bar]
Max Transmi er
Pressure:
4,000 psi [276 bar]
Opera onal
Principle:
Hydraulic Pressure
Pig Type: Any
Installa on: Flange-bolted to transmi er
Sensor Type: Sub-Miniature
Pressure Switch
Construc on: 316 Stainless Steel
Repeatability: 3% of Ac va on
Pressure
Proof Pressure: 6,000 psi [414 bar]
Burst Pressure: 9,000 psi [600 bar]
Opera ng Temp
Range:
32°–230°F [0°–110°C]
