22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 6 of 52
CD42ͳTͳSERIES QUICKͳSTART
2. PLACE TRANSMITTER INTO SERVICE CONT.
FOAM AND PLASTIC PIGS:
Remove plug or bolt
Place transmi er into cavity
(transmi er may be aligned
in either direc on)
Replace plug/bolt
CHECKLIST
Before placing a transmi er into service, always ensure:
• Ba eries are fresh and of proper size and type.
• Ba ery polarity is properly observed.
• Serviceable O-rings are installed. Bri le and/or deformed
O-rings may not properly seal, thus compromising case integrity.
• Transmi er case, caps, and cap threads and or cap screws are
clean and free of dents, ruptures, or other damage which could
compromise the transmi er components.
TROUBLESHOOTING
Connec on and Communica on
CDI transmi ers, when supplied with fresh ba eries of the proper size
and type, should automa cally transmit an electromagne c signal unless
custom-programmed at the factory for Delay On behavior.
If your transmi er fails to establish communica on a er following all
ba ery installa on procedures, contact CDI at 1-800-580-4234 or
918-258-6068 for product support.
REMOVING TRANSMITTER FROM SERVICE
Remove ba eries from transmi er and carousel before storage.
WARNING:
Always remove ba eries before placing the unit into storage.
Failure to do so may result in damage and may void warranty.
