Legenda schema elettrico
1 Bobina contattore linea 2 Bobine trasformatore 3 Contattore
di linea 4 Commutatore tensione 5 Connettore torcia 6 Diodi
7 Elettrovalvola gas 8 Connettore cambio tensione di alimen-
tazione (rosso) 9 Connettore cambio tensione di alimentazione
(blu) 10 Inizio bobina 11 Interruttore di linea 12 Induttore 13
Lampada spia termostato 14 Connettore cambio tensione di
alimentazione (bianco) 15 Motore trascinatore 16 Motore ven-
tilatore 17 Potenziometro tempo puntatura 18 Potenziometro
velocità filo 19 Morsetto massa 20 Pulsante torcia 21 Resistore
22 Raddrizzatore 23 Scheda elettronica 24 Trasformatore
ausiliario 25 Torcia Mig Mag 26 Trasformatore principale 27
Termostato raddrizzatore 28 Termostato trasformatore 29
Varistore raddrizzatore secondario
Key to the electrical diagram
1 Line counter coils 2 Transformer coils 3 Line counter 4
Voltage switch 5 Electronic drive circuit 6 Diodes 7 Gas sole-
noid 8 Change-over input voltage connector (red) 9 Change-
over input voltage connector (blue) 10 Coil start 11 Line circuit
breaker 12 Inductor 13 Thermostat indicator light 14 Change-
over input voltage connector (white) 15 Drive motor 16 Fan
motor 17 Wire speed potentiometer 18 Spot welding time po-
tentiometer 19 Earth terminal 20 Torch button 21 Resistor 22
Rectifier 23 Electronic circuit board 24 Auxiliary transformer
25 Mig Mag torch 26 Main transformer 27 Rectifier thermo-
stat 28 Transformer thermostat 29 Secondary rectifier varistor
Légende schéma électrique
1 Bobine contacteur ligne 2 Bobine transformateur 3 Contac-
teur de ligne 4 Commutateur de tension 5 Connecteur torche
6 Diodes 7 Electrovanne du gaz 8 Connecteur pour le char-
gement de la tension du réseau (rouge) 9 Connecteur pour le
chargement de la tension du réseau (bleu) 10 Début bobine 11
Interrupteur de ligne 12 Inducteur 13 Lampe témoin thermos-
tat 14 Connecteur pour le chargement de la tension du réseau
(blanc) 15 Moteur dentraînement 16 Moteur ventilateur 17
Potentiomètre vitesse du fil 18 Potentiomètre temps de saudage
pour pointage 19 Borne masse 20 Bouton poussoir de la tor-
che 21 Résistance 22 Redresseur 23 Fiche électronique 24
Transformateur auxiliaire 25 Torche Mig Mag 26 Transforma-
teur principal 27 Thermostat redresseur 28 Thermostat trans-
formateur 29 Varistance redresseur secondaire
Schaltplan-Legende
1 Bobine von dem Leistungkontaktgeber 2 Transformatorspule
3 Leistungkontaktgeber 4 Spannungsumschalter 5 Brenner-
verbinder 6 Dioden 7 Gaselektroventil 8 Steckvorrichtung für
Spannungswechsel (rot) 9 Steckvorrichtung für Spannungs-
wechsel (blau) 10 Spulenanfang 11 Betriebsschalter 12 Dros-
selspule 13 Kontrolleuchte-Thermostat 14 Steckvorrichtung für
Spannungswechsel (weiß) 15 Mitnehmermotor 16 Lüftermotor
17 Potentiometer Drahtgeschwindigkeit 18 Punktschweißzeit-
Potentiometer 19 Masseanschluss 20 Brennerschalter 21
Widerstand 22 Gleichrichter 23 Elektronikkarte 24 Hilfstrans-
formator 25 Mig Mag Brenner 26 Haupttransformator 27 Ther-
mostat Gleichrichter 28 Transformator-Thermostat 29 Sekun-
därer Gleichrichtervaristor
Leyenda esquema eléctrico
1 Bobina del contactor de línea 2 Bobinas transformador 3
Contactor de línea 4 Commutador de tensión 5 Conector an-
torcha 6 Diodos 7 Electroválvula gas 8 Conector cambio de
tensión de alimentación (rojo) 9 Conector cambio de tensión de
alimentación (azul) 10 Inicio bobina 11 Interruptor de línea 12
Inductor 13 Lámpara testigo termostato 14 Conector cambio
de tensión de alimentación (blanco) 15 Motor arrastre 16 Mo-
tor ventilador 17 Potenciómetro velocidad hilo 18
Potenciómetro tiempo de suldadura para punteado 19 Borne
masa 20 Pulsador antorcha 21 Resistor 22 Rectificador 23
Tarjeta electrónica 24 Transformador auxiliar 25 Antorcha Mig
Mag 26 Transformador principal 27 Termóstato rectificador 28
Termostato transformador 29 Varistor rectificador secundario
Legenda elektrisch schema
1 Bobine contactor op lijn 2 Spoelen transformator 3 Contactor
van de lijn 4 Omschakelaar spanning 5 Stik til svejsebrænder
6 Dioder 7 Elektroventil for gas 8 Connector voor verandering
netspanning (rood) 9 Connector voor verandering netspanning
(blauw) 10 Âegin spoel 11 Netschakelaar 12 Inductor 13
Thermostaat controlelampje 14 Connector voor verandering
netspanning (wit) 15 Voortsleepmotor 16 Ventilatormotor 17
Potentiometer draadsnelheid 18 Potentiometer puntlastijd 19
Massaklem 20 Toortsknop 21 Weerstand 22 Gelijkrichter 23
Elektronische kaart 24 Hulptransformator 25 Mig Mag toorts
26 Hoofdtransformator 27 Thermostaat gelijkrichter 28 Ther-
mostaat transformator 29 Varistore secundaire gelijkrichter
BCL BOB A-B-C CL CR CT D EVG FCS C1 FCS C2 Ib IL L LS MCSC
•1 •2 •3 •4 •5 •6 •7 •8 •9 •10 •11 •12 •13 •14
•15 •16 •17 •18 •19 •20 •21 •22 •23 •24 •25 •26 •27 •28 •29
MT MV P1 P2 PM PT R RS SE TA TM TP TR TT V
Legenda
colori
AN Arancione Nero
AR Azzurro Rosso
Ar Arancio
Az Azzurro
BR Bianco Rosso
Bc Bianco
Bl Blu
GV Giallo Verde
Gg Grigio
Gl Giallo
Mr Marrone
NA Nero Azzurro
Nr Nero
RN Rosso Nero
Ro Rosa
Rs Rosso
Vd Verde
Vl Viola
Colour
key
AN Orange Black
AR Blue Red
Ar Orange
Az Sky Blue
BR White Red
Bc White
Bl Blue
GV Yellow Green
Gg Grey
Gl Yellow
Mr Brown
NA Black Blue
Nr Black
RN Red Black
Ro Pink
Rs Red
Vd Green
Vl Violet
Légende
couleurs
AN Orange Noir
AR Bleu Rouge
Ar Orange
Az Bleu Clair
BR Blanc Rouge
Bc Blanc
Bl Bleu
GV Jaune Vert
Gg Gris
Gl Jaune
Mr Marron
NA Noir Bleu
Nr Noir
RN Rouge Noir
Ro Rose
Rs Rouge
Vd Vert
Vl Violet
Farbenl-
egende
AN Orange Schwarz
AR Hellblau Rot
Ar Orange
Az Hellblau
BR Weiß Rot
Bc Weiß
Bl Blau
GV Gelb Grün
Gg Grau
Gl Gelb
Mr Braun
NA Schwarz Hellblau
Nr Schwarz
RN Rot Schwarz
Ro Rosa
Rs Rot
Vd Grün
Vl Violett
Leyenda
colores
AN Anaranjado Negro
AR Azul Rojo
Ar Anaranjado
Az Azul
BR Blanco Rojo
Bc Blanco
Bl Azul
GV Amarillo Verde
Gg Gris
Gl Amarillo
Mr Marrón
NA Negro Azul
Nr Negro
RN Rojo Negro
Ro Rosa
Rs Rojo
Vd Verde
Vl Violeta
Kleuren-
legenda
AN Oranje Zwart
AR Blauw Rood
Ar Oranje
Az Blauw
BR Wit Rood
Bc Wit
Bl Donkerblauw
GV Geel Groen
Gg Grijs
Gl Geel
Mr Bruin
NA Zwart Blauw
Nr Zwart
RN Rood Zwart
Ro Roze
Rs Rood
Vd Groen
Vl Paars
