4.2.2 Filling the fuel tank
ATTENTION!
Observe the warnings in the motor
operating manual regarding the handling
of fuel.
Use only diesel fuel.
1. Open the lid of the fuel tank at the CF-2116 D motor
(g. 4.3).
2. For lling in fuel use a funnel with strainer in order to
avoid pollution of the tank and the fuel.
Filling quantity and type of fuel are indicated in chapter
2.1 and section 6.7.
CF-2116 D fuel tank (tank lid) Fig. 4.3
4.2.3 Checking lling level of
cutting shaft lifting hydraulic
The CF-2116 D is supplied with lled hydraulic uid
for the cutting shaft’s lifting hydraulic. The correspond-
ing compact hydraulic unit is incorporated in the front
left part of the superstructure box and accessible after
removal of the water tank.
Check the lling level of the cutting shaft’s lifting hy-
draulic before the rst use and then according to the
maintenance table (refer to sections 6.5 and 6.6.7).
If there is not sufcient hydraulic uid the cutting
shaft and thus the diamond saw blade cannot be
lifted by means of the quick-lifting!
4.2.4 Checking lling level of
hydraulic uid
in hydrostatic feed gear
The hydrostatic feed gear is part of the CF-2116 D
travel drive. It is located in the lower left part of the
superstructure box and accessible after removal of the
water tank.
The joint cutter is supplied with lled hydraulic uid for
the hydrostatic feed gear.
Check the lling level of the hydrostatic feed gear
before the rst use and then according to the mainte-
nance table (refer to sections 6.5 and 6.6.6).
In case of insufcient hydraulic uid the joint cutter
cannot be displaced trouble-free by means of the
feed drive. The diamond saw blade will be worn
faster or might be damaged.
4.2.5 Checking the tension
of the cutting shaft V-belts
ATTENTION!
Check the V-belts (tension) after
10 operating hours!
After the rst commissioning of the CF-2116 D and/or
after having replaced the cutting shaft’s V-belts they
have to be checked and, if necessary, re-tensioned
after 10 operating hours.
The 4 cutting shaft’s V-belts for the blade drive are
located under the V-belt cover in front left of the ma-
chine’s travel direction (g. 1.1, 4.4 and 4.5).
