2.0 Technical data and accessories
2.1 Technical data of the CF-2116 D
Design Standard Green concrete
Type
Drive motor
Motor output
Fuel
Contents fuel tank
Fuel consumption
AYHP
Hatz-Diesel 2G40
14,7 kW
Diesel
7,0 l
approx. 235 g/kWh, approx. 4,4 l/h
Cutting shaft speed
Max. saw blade-Ø
Max. cutting depth
1400 rpm
800 mm
300 mm
2250 rpm
400 mm
100 mm
Diameter blade receptacle 25,4 mm
Max. blade mounting width 20 mm
Drive pin 8 mm Ø on 28,7 mm hole circle radius
Blade receptacle right or left
Feed hydrostatic feed gear
Cutting depth adjustment,
lowering speed of cutting shaft
manual-hydraulic pre-adjustment (buttery valve)
Cutting shaft quick-lifting electro-hydraulic (compact hydraulic unit)
Output of electric motor (compact
hydraulic unit)
0,40 kW
Emergency lowering manual-hydraulic (shut-off valve)
Connection for pressured water Geka-coupling with shut-off valve and dirt trap
Water pump electrically driven impeller pump, 18 l/min
Operating hour meter yes
Electric battery (starter) 55 Ah
Electric starting prevention yes
Acoustic signal (horn) in case of lack of motor oil
Motor starting device electric starter
Emergency stop mechanical
Water tank 35 l (removable, with shut-off valve)
Dimensions length x width x height 1300 x 1000 x 1150 mm
Weight (empty / lled water tank) 340 kg / 375 kg 330 kg / 365 kg
Sound pressure level at place of work
(Lpa)*
96,0 dB(A)
The motor operating manual is decisive for all data concerning the drive motor!
* During cutting operation higher sound levels are possible to occur!
