Trouble shooting, what if …?
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
8.2 Problems with the electrical system of the CF-2116 D
Problem Possible cause Remedy
The electric motors
(starters, stroke/
compact-hydraulic
power pack) will not
start when switched
on
Connection cable is notproperly
tightened
A switch is defect
A loose connection in the
electric system
Electric motor is defect
A fuse has blown
Damage to the electrical system
Connect the cables correctly (let them be checked by
a qualied electrician and, if necessary, have them
exchanged
Let the switch be checked by a qualied electrician
and, if necessary, have it exchanged
Let the complete electric system be checked by a
qualied electrician
Let the electric motor be checked by a qualied
electrician or work-shop, if necessary, have it
exchanged
Let the cause be rectied by a qualied electrician and
then change the fuse
Let the cause be rectied by a qualied electrician
Stroke works
unevenly
Electric motor does not hold its
Rpm (speed)
Let the electric motor be checked by a qualied
electrician or work-shop, if necessary, have it
exchanged
8.3 Problems with the hydraulic system of the CF-2116 D
Problem Possible cause Remedy
Feed drive does not
run
The V-belt of the hydraulic gearing is
slipping
Drive chain is loose or defective
The hydrostatic gearing is short of oil
Clutch is not properly engaged
Tension the V-belt, if necessary, renew
Tension drive chain and replace if necessary
Check the oil level of the hydrostatic gear box, if
necessary, top up the oil
Engage the clutch properly
The blade shaft can-
not be completely
lifted
Not enough oil in the compact hydrau-
lic power pack
Air in the hydraulic system
Replenish the hydraulic oil In the hydraulic
system
Bleed off (vent) the hydraulic system
The blade shaft does
not lower fully
The hydraulic cylinder and/or the
rocker are jammed
Straighten the rocker, if necessary, change the
cylinder
The blade shaft sinks,
even when the valve
is closed
Valve for lowering the blade is defect
Hydraulic coupling (union) is Leaking
The hydraulic cylinder leaks
Change the lowering valve
Re-tighten the union (coupling)
Change the seals
