Maintenance and care
Joint cutter CF•22 E
Before every start-up
After nishing work
Every working day
Initially after 10 h
Weekly Monthly After
3 - 6 months
Annually In case of
disturbances
In case of damages
Entire machine
3 1 3 3
Electrical system (switches, ...)
7 7 7 7 7 4
Tool holder (ange and saw blades holder)
1, 3 3 4
Tool (diamond saw blade)
3, 6 1 4
Control elements (hand crank, ....)
3 1 4
V-belt
3 3, 5 3 4 3 4
Threaded spindle
2 3 4
Motor housing
1
Motor
3, 7
Parking brake
3 3, 5 4
Reachable connecting elements (nuts, screws, ...)
5
h = Operating hours 1 Clean 2 Lubricate, grease, oil, corrosion protection 3 Control (visual inspections, function)
4 Change, exchange 5 Retighten, adjust, change wear parts 6 Change as required
7 Legally required safety inspection (see section 5.6)
The description of the maintenance work can be found in the following and respective chapters of this operating manual! The table can be updated at any time by CEDIMA® (for example appropriate technical requirements and developments)! Inform yourself by contacting CEDIMA®!
5.5 Maintenance intervals for the CEDIMA® joint cutter CF•22 E
