Cellink BIO X - Product Map

12
2.1 Product map
3a
3b
1
6
7
3c
4a
5
4b
2a
2b
1. Clean Chamber ™ unit
2a. UV sterilizaon LED 1
2b. UV sterilizaon LED 2
3a. Printhead mount 1
3b. Printhead mount 2
3c. Printhead mount 3
4a. Photo-curing module mount 1
4b. Photo-curing module mount 2
5. Print bed
6. 7-inch touchscreen
7. USB port
8. Protecve door
8
