6 Vessel and Accessories Overview
Vessel and Accessories Overview
For a list of parts and part numbers, visit our website at www.cem.com. A list of parts can be found on the
“Products” page under “MARS 6”.
Vessel Components
WARNING
Only use vessels and vessel components purchased directly from CEM or through its authorized dealer
network. The use of vessels and vessel components other than original CEM parts will put operators and
equipment at risk; therefore, CEM will not assume any liability for use of these parts and all warranties,
either written or implied, will immediately become void.
1
5
4
3
2
6
Item Description
1 Frame Module Supports sleeve, load disc, vessel liner, plug and screw
2 Sleeve Supports vessel liner
3 Load Disc Evenly distributes load from plug
4 Vessel Liner Contains acid and sample. 110 mL Liner (5 -30 mL working volume)
5 Plug Seals liner to contain acid and sample
6 Frame Screw Uniformly provides pressure seal among vessels when torqued
To Next Page
