Cembre MG4 - Printer Installation Guide; Device Overview and Components

6
1.1 Device overview
Installation2
2.1
1 Mobile carriage
2 Button to open/close sheet loading carriage.
3 Upper lid
4 Five inch LCD touch screen display
5 Battery contact protection lid
6 Battery release button
7 ON/OFF switch
8 10/100 Base-T ethernet port
9 Type A USB socket
10 Type B USB socket
11 Power supply connection socket
Fig. 2a
Fig. 2b
2
3
4
1
5
6
7
8
9
10
11
6
