S700 Taximeter Operating & Programming Guide
5
SWITCH DEFINITION - TAXIMETER MODE
SWITCH
VACANT STATE
HIRED STATE
TIME
-
OFF STAT
E
STATISTICS STATE
SW1
Hired
----
Vacant
Exit Statistics State
SW2
Toggle Display Brightness
Time Off
Time On
Reset Stats
4
SW3
Stats
De
crement Extras
Sum Fare & Extras
Add/Display Tax Amount
1,3
Decrement Stats
SW4
Menu Mode
In
crement Extras
----
Increm
ent Stats
SW5
Print Receipts On Printer
----
Print Receipts On Printer
Print Statistics On Printer
SW6
Increment Rate
Increment
2
Rate
Increment
2
Rate
Toggle Between Total Statistics &
Daily Statistics
NOTES:
1. Tax amount and method must be programmed.
2. Requires that Lockout Rate Changes While Hired is disabled.
3. Press SW3 once while in Hired Time-Off to sum fare and extras in the fare display. If the tax value is non-zero, pressing
SW3 a second time (within 5 seconds of the 1
st
press) will sum fare+extras+tax in the fare display.
4. Need to press and hold for 2 seconds.
Statistics Mode
The statistics mode can be entered only from the Vacant state by pressing switch 3. Upon entering this mode, the Stats legend is lit. The fare and
extras displays show the first item of total statistics - total fares, and the rate display shows the item number.
The following functions are available from the Statistics state:
 Print statistics by pressing switch 5
 View statistics items by pressing switch 4 to go to next item or switch 3 to previous item
 Reset statistics
Pressing switch 6 toggles between total statistics and daily statistics. To differentiate between these two sets of data, when displaying daily statistics,
there is a letter‘d’ before the item number in the rate window.
The items displayed are as follows:
Item Number
Statistic
Rate Digit
1
Total Fares
1
2
Total Units
2
3
Total Extras
3
4
Total Taxes
4
5
Total Miles (Or
Kilometres
)
5
6
Total Paid Miles (Or
Kilometres
)
6
7
Numb
er Of Trips
7
While in either total statistics or daily statistics, the statistics items can be reset to zero by holding switch 2 for 2 seconds. For total statistics this
requires that the statistics reset option is enabled in programming. Both sets of statistics data can be optionally protected by passwords. The correct
total statistics reset code has to be entered to clear total statistics, unless this item is set to zero. Similarly, the correct daily statistics reset code has
to be entered to clear daily statistics, unless this item is set to zero. If an incorrect reset code is entered, the fare display will blink five times. For
more information on how to enter a reset code, refer to the “Edit Data” section. Each time that the total statistics are reset, a counter is incremented
and the current count appears at the bottom of the printed total statistics report.
The statistics data can be displayed for the programmed statistics timeout period if there has been no switch press. If a switch is pressed before the
programmed Statistics timeout period has elapsed, the display will remain on for a further timeout period. The taximeter will automatically revert to
the Vacant state if the vehicle moves or when the programmed statistics timeout period has elapsed.
