S700 Taximeter Operating & Programming Guide
9
Menu – 7 (Disable Date Menu & Lease Period)
This menu will be skipped over if the disable meter at date option and lease period are not enabled. Menu #7 allows the operator to display the
current date and time that are stored for the Disable Meter At Time And Date and the Lease Period number of days. To edit the values the password
must first be entered. Press switch 6 and you will be prompted to enter the password. If the correct password is entered the first item disable
Hours:Minutes is displayed and may be edited using switch 3 and 4 to lower or raise the value, use switch 2 and 5 to select digit to be edited, and
finish by pressing switch 6 to record the new value. Press switch 4 to select the next item and continue editing in the same fashion.
Item
Number
Fare Display
Extras Display
Rate Display
1
disable Meter: HOURS:MINUTES
1
7
2
disable Meter:
Day/month
2
7
3
disable Meter: Year
3
7
4
Lease period: Days
4
7
Menu – 8 (Not used)
Menu – 9 (Not used)
Menu – 10 (Trip Receipt Menu)
Menu #10 allows the operator to print stored receipts and to reset the stored receipts pointer. Press switch 6 and item number 1 is displayed. Press
switch 5 to begin printing the stored receipts (if password is enabled you will be prompted to enter the password). The number of stored receipts is
shown in the Fare display. You may press switch 1 to stop printing at anytime. To reset the number of stored receipts pointer, press switch 4 to
select item 2, press switch 6 to reset pointer (if password is enabled you will be prompted to enter the password) and the word DONE is shown in the
Fare display.
Item
Number
Fare Display
Extras Display
Rate Display
1
Print stored receipts since last print
1
10
2
Reset store receipts pointers
2
10
Programming Mode
Programming mode can be entered from Vacant by removing the seal screw and cover from the front of the taximeter and sliding the programming
switch 7 to the left position. Upon entering programming mode, all the legends become off, and the first program group number flashes in the rate
display. If the password option is enabled, the first group number displayed will be 6, otherwise it will be 0. While in program mode with group
number flashing, press switch 4 to increment through the group list, or press switch 3 to decrement.
Except for Program Group #1 (Rates Group), when the desired group number is displayed flashing, press switch 6 to select it. The rate display will
then display the group number on steady. The first item in the selected group will be shown in the fare display, and the item number in the extras
display. If the selected group has more than 1 item, pressing switch 4 will increment through the list of items and pressing switch 3 will decrement
through the list of items.
When Group #1 (Rates Group) is displayed flashing in the rate display, the rate legend will also be lit flashing. Press switch 6 to enter Rates group.
The rate legend becomes on steady. Rate 1 flashes in the rate display. Press switch 4 to increment through the rate numbers, or press switch 3 to
decrement. When the desired rate number is displayed flashing in the rate display, press switch 6 to select it. The rate number becomes on steady.
The drop fare for that rate is now displayed in the fare display, and item number in the extras display. Again, pressing switch 4 will increment through
the list of items and pressing switch 3 will decrement through the list of items.
If the password option is not enabled, to program a group item, press switch 6 when the item is displayed. If the password option is enabled, the
correct password has to be entered before any editing can take place.
