Maximum gate length & mass:
*Subject to system power supply. Standard battery driven system with 7A/H battery is limited to 20 operations per
day.
# For pedestal mount installations where the gate exceeds 3m, and wall mount installations where the gate
exceeds 2,5m, it is recommended that an electric lock be fitted.
† This applies only to STANDARD pedestal mount installations installed according to the RECOMMENDED positions.
Gate Length:
For a 1.8m high gate, 25% coverage:
For a 1.8m high gate, 100% coverage:
110km/h
55km/h
82km/h
41km/h
66km/h
33km/h
55km/h
27km/h
47km/h
23km/h
Max. Allowable Leaf Mass:
Max. wind speeds for which the operator
†
will open the gate :
1,5m
1000kg
2,0m
550kg
2,5m#
350kg
3,0m#
250kg
3,5m#
180kg
SPECIFICATION
R3
Voltage (with power supply unit)CP84ER5V01CP84ER5V01Voltage (with power supply unit)CP84ER5V01
220V AC ±10% 50Hz
AC Current draw (with power supply unit)CP84ER5V01CP84ER5V01AC Current draw (with power supply unit)CP84ER5V01
120mA
DC Current draw (Max)
15A
Maximum solenoid lock current draw
2A
Output shaft rotational speed
3.5 rpm
Maximum output torque
140Nm
Maximum number of operations per day (Average)
100*
Maximum number of continuous operations
20
Typical time to open/close a gate
(For standard pedestal in recommended position)
10 seconds
No. of operations on a 7A/H battery (should the mains power fail)
±20
Limit switches
Sealed optical counter
with origin switch
Collision sensitivity
Electronic adjustable
Temperature range
o
-20 to +50 C
Housing protection
IP55
Control card (single or double motor)
CP75
Corrosion protection (baseplate and arms)
Zinc electro galvanising
SpecificationsSpecificationsSpecifications
