page 10 www.centsys.com
2.2. Technical Specications
T10 T12
Input voltage 230V AC @ 50/60Hz
1
Motor voltage 24V DC
Motor power - rated 80W DC 100W DC
Motor supply
Battery supply 2x 12V
3.4Ah
Battery supply 2x 12V
3.4Ah
Max door width 6500mm
Max door area 12 square metres 15square metres
Max holding capacity 1000N 1200N
Maximum push/pull
force
40kgf 50kgf
Operations in standby
mode
Up to 90 depending on the door size / weight / height /
duration of power failure / condition of batteries
Operator travel speed
3
9m/min
Door travel adjustment Physical Endstops (Automatic limit set)
Safety obstruction force
system
Built-in menu
Light LED 2W
Autoclose
2
Menu Selectable
Infrared safety beams
Menu Selectable.
(Optional, but recommended)
Radio receiver Code-hopping 433MHz
Receiver code storage
capacity
20x 4-Button NOVA transmitters
1: Can operate o a solar supply, please consult Centurion Systems (Pty) Ltd for assistance
2: Requires infrared safety beams to be tted
3: Speed varies with load
TABLE 1
TABLE 2
2.3. Fuse Protection
The following protection fuses are provided on the system:
Item Type Rating
Main controller
Motor circuit ATO 15A
SPECIFICATIONSSECTION 2
