Centurion SDO4 SMART - Product Identification; Fasteners List and Spares

page 11 www.centsys.com
1. Control head unit
2. Rail
3. Release handle with warning label
4. Straight towing arm
5. Towing bracket
6. Bent towing arm
7. Header bracket
8. Tensioning nut and spring
9. Drive Belt
10. End stop
11. Carriage
12. Belt bullet
13. Head unit brackets
14. Rail hanger
15. Battery housing
16. Screw to remove the Control Head Cover
FIGURE 2. PRODUCT IDENTIFICATION
1
2
4
14
12
15
16
5
13
11
6
3
Towards garage door
END B
8
7
3. Product Identication
END B
END A
10
9
PRODUCT IDENTIFICATIONSECTION 3
