CESAB B 200 - ELECTRIC DISTRIBUTOR SYSTEM CONFIGURATION

4-7
0
1
2
3
4
3
6
7
8
9
10
11
12
13
14
15
16
17
18
ELECTRIC DISTRIBUTOR SYSTEM CONFIGURATION
JT (20)
JT (21)
J40 (8)
J40 (15)
J34 (21)
J34 (22)
J34 (23)
J34 (33)
J34 (34)
J34 (35)
JP (20)
JP (21)
J133 (4)
J133 (5)
J132 (3)
J132 (4)
J137 (1)
J137 (2)
J137 (8)
J137 (9)
J138 (2)
J138 (4)
180 Ω
180 Ω
180 Ω
J140 (4)
J140 (13)
LOGIC UNIT
TRACTION
LOGIC UNIT
LIFTING
SESAM KEYPAD
ARMREST
CARD
I/O CARD
MHYRIO UNIT DASHBOARD
CAN LOW
CAN HIGH
Color: GRAY/YELLOW
Color: BLUE/BLACK
CAN-BUS SOCKET
PROGRAMMER
