CONTACTOR GROUP
REMOVAL • INSTALLATION
Removal procedure
1. Remove the boot
2. Move the seat forward
3. Move the lever of the mechanic control valve forward (only with mechanic control valve version)
4. Open the battery cover
5. Disconnect the battery
6. Remove the two fixing screws of the battery connector group
7. Disconnect the power cables from the contactors
8. Remove the contactors
Installation procedure
The reassembly procedure is the reverse of the disassembly procedure.
