0-14
MEMBER WEIGHTS
Member Vehicle model Weight (Kg)
Battery
100 372 ÷ 420
125 600 ÷ 690
150 676 ÷ 780
Drive motor 100 - 150 ~ 34
Pump motor (Hydraulic pump + electric motor) 100 - 150 ~ 40
Rear axle (without wheels and dry) 100 - 150 ~ 53
Counterweight 100 - 150 ~ 900
Mast with lift brackets (with lift cylinder, without forks, lifting
height 4350 mm, 2M T.V.)
100 - 150 ~ 450
Vehicle weight (w/battery)
100 ~ 2550
125 ~ 2820
150 ~ 2930
