B4 WATCHDOG MHYRIO LOGIC UNIT: Self-diagnostic test 4-52
B5
EVP DRIVER
SHORTED
MHYRIO LOGIC UNIT: The valve driver is in short circuit 4-52
C1 STOP OPEN I/O CARD: Failure on the stop lights 4-66
C2
ANT_OPEN or
POST_OPEN
I/O CARD: Failure on front or rear light circuit 4-66
C3 UNUSED UNUSED 4-67
C4 RETRO OPEN I/O CARD: Failure on the reverse lights. 4-67
C5 TILT_LOCK_FAULT I/O CARD: Tilt solenoid valve coil failure 4-67
C6
LOWERING_LOCK_
FAULT
I/O CARD: Lifting solenoid valve coil failure 4-67
C7
STATIONARY_
BRAKING_BUZZER_
FAULT
I/O CARD: Alarm buzzer fault 4-67
D1 TRAC KO DASHBOARD: The traction logic unit is not detected 4-58
D2 I/O CARD KO DASHBOARD: The I/O card is not detected 4-58
D3 UNUSED UNUSED 4-58
D4 PUMP KO DASHBOARD: The lifting logic unit is not detected 4-59
D5 MHYRIO KO DASHBOARD: The mhyrio logic unit is not detected 4-59
D6 JOY KO DASHBOARD: The arm rest board is not detected 4-59
D7 BRAKE LEVEL DASHBOARD: Brakes oil level low 4-60
D8 ERROR READ PIN DASHBOARD: Configuration error with the I/O card 4-60
D9 DHU KO DASHBOARD: The DHU board is not detected 4-60
DA SHOCK LOCKOUT DASHBOARD: Unused 4-60
BOM UNUSED UNUSED 4-61
DC UNUSED UNUSED 4-61
DD SAS KO DASHBOARD: The SAS board is not detected 4-61
DE UNUSED UNUSED 4-61
DF EEPROM ERROR DASHBOARD: Memory fault 4-61
E1
PUMP INCORRECT
START
ARMREST CARD: Incorrect starting procedure 4-53
E1
PUMP INCORRECT
START
I/O CARD: Incorrect starting procedure 4-62
E2 BAD LIFT POT ARMREST CARD: Failure on the lifting potentiometer 4-54
E2 BAD LIFT POT I/O CARD: Failure on the lifting potentiometer. 4-62
E3 BAD TILT POT ARMREST CARD: Failure on the tilting potentiometer 4-54
E4 BAD SIDESHIFT POT ARMREST CARD: Failure on the tilting potentiometer 4-55
E5 BAD IV POT ARMREST CARD: 4th way potentiometer failure 4-55
E6 BAD V POT ARMREST CARD: 5th way potentiometer failure 4-56
E7 DEFAULT RESTORED ARMREST CARD: Alarm 4-56
When an Error Code is Displayed
Code Alarm specification Error mode Page
