CESAB B 200 - Page 173

4-25
0
1
2
3
4
3
6
7
8
9
10
11
12
13
14
15
16
17
18
30 UNUSED
0A SAFETY OUTPUT
Condition for error detection
SAFETY IN control output connector JT pin 19.
Logic unit SAFETY driver defect.
Check the truck insulation (see paragraph INSULATION CONTROL PROCEDURE)
Replace the logic unit.
0B SLIP PROFILE
Condition for error detection
Error in the memory data where the flowing parameters are loaded.
Make a logic unit RESET to re-load the default parameters.
If the error persists when the machine is switched back on, install the last version of the software using
the programmer.
If the problem presists replace the logic unit.
0C ANALOG INPUT
Condition for error detection
Control internal error.
• check the tuck and motor insulation (INSULATION CONTROL PROCEDURE and MOTOR WINDING
CONTROL PROCEDURE)
• check the connections and wiring harnesses
• check the sensors and potentiometers connected to the logic unit
Replace the logic unit.
0D HARDWARE FAULT
Condition for error detection
Control internal error.
• check the tuck and motor insulation (INSULATION CONTROL PROCEDURE and MOTOR WINDING
CONTROL PROCEDURE)
• check the connections and wiring harnesses
• check the sensors and potentiometers connected to the logic unit
Replace the logic unit.
