CESAB B 200 User Manual

4-60
D7 BRAKE LEVEL
Condition for error detection
Brakes oil level low.
Check the wiring harness and the microswitch on the brake oil tank
D8 ERROR READ PIN
Condition for error detection
Configuration error between the I/O card and the instrument panel
If the key reset does not eliminate the alarm:
• RESET the instrument panel and the I/O card
• Install the latest version of the software via the PROGRAMMER
D9 DHU KO
Condition for error detection
Can-bus comunication failure. The alarm appears if the display does not receive information from the
DHU board.
Before replacing any board:
- Check if the board is powered
- Can-bus pull-up resistance presence
• Instrument panel 180 Ohm
• MCB 180 Ohm
• Arm rest 180 Ohm
- Check the connections, pins and wiring harness on the can-bus
See paragraph SYSTEM CONFIGURATION WITH MECHANICAL/ELECTRIC DISTRIBUTOR
DA SHOCK LOCKOUT
Condition for error detection
Can-bus comunication failure. The alarm appears if the display does not receive information from the
SHOCK SENSOR.
Before replacing any board:
- Check if the board is powered
- Can-bus pull-up resistance presence
• Instrument panel 180 Ohm
• MCB 180 Ohm
• Arm rest 180 Ohm
- Check the connections, pins and wiring harness on the can-bus
