INSPECTION • ADJUSTMENT
Brake pump play adjustment
• Move the nut A to have a play of 0,2 - 0,5 mm
Brake fluid system bleeding
• Loosen the cap and press the brake pedal and let go out
the air
• Repeat the procedure untill the air doesn’t go out
• Tight the cap
• Repeat the procedure on the other reduction gear
