CESAB B 200 - CYLINDER SPECIFICATIONS

12-3
0
1
2
3
4
5
6
7
8
9
10
12
12
12
12
15
16
16
18
CYLINDER SPECIFICATIONS
SIDE / REAR LIFTING CYLINDERS (2M TV & 3M TV)
SIDE / REAR LIFTING CYLINDERS (3M TV)
CENTRAL LIFTING CYLINDERS (2M TV & 3M TV)
SIDE / REAR LIFTING CYLINDER (2M FFL)
Model
Item
1.0 t 1.25 t 1.5 t
Cylinder model Simple effect
Cylinder bore mm 42 ←←
Piston outside diameter mm 36 ←←
Parachute valve s = 1 ←←
Opening ø = 0.6 ←←
Model
Item
1.0 t 1.25 t 1.5 t
Cylinder model Simple effect
Cylinder bore mm 45 ←←
Piston outside diameter mm 38 ←←
Parachute valve s = 1.5 ←←
Opening ø = 0.6 ←←
Model
Item
1.0 t 1.25 t 1.5 t
Cylinder model Simple effect
Cylinder bore mm 45 ←←
Piston outside diameter mm 38 ←←
Parachute valve s = 1.2
←←
Opening ø = 0.6 ←←
Model
Item
1.0 t 1.25 t 1.5 t
Cylinder model Simple effect
Cylinder bore mm 35 ←←
Piston outside diameter mm 25 ←←
Parachute valve s = 1.5 ←←
Opening ø = 0.6 ←←
