14-15
14
LIFTING LOCKING AND UNLOCKING SCREW
T=Nm
• Loosen the lift lock unlocking bolt and operate the lift lever to manually lower the forks.
Notes:
Always retighten the locking bolt after an operation. If lift locking and unlocking bolt is left loose,
much hydraulic oil is released from the pump and the lifting speed is significantly decreased,
resulting in difficulty in smooth operation.
Lifting locking-unlocking screw
