CONNECTOR INSPECTION
When inspect each board and find the cause of the trouble, do not replace the board immediately but
check the following items.
• Abnormalies in related harnesses
• Looseness of the related connectors
• Bending or damage of connector pin and defective contact of any related connector pin
If any of the above is the cause of the trouble and the board is replaced with a new one, the new board
will be damaged.
Always replace the board after careful inspection.
When the trouble derives from a logic unit or board, measure the voltage and resistance of every part
involved in the substitution. Always disconnect the battery plug before measuring the resistance.
Important:
Disconnect the battery plug before connecting or disconnecting the logic unit.
Note:
When a logic unit is determined to be the cause of trouble as the result of troubleshooting,
always measure the applied voltage and resistance of each related portion when replacing.
(1)Setting Method
(a)Key switch OFF and battery plug disconnected.
(b)Connect the multimeter to the corresponding connector pin
Important:
As connection of the wrong connector pin may damage normal portions, make sure to confirm
the connector pin number.
(2)Measurement method and standard list
How to read the list
COLOUR CODING
CN (pin-colour) ⇔ CN (pin-colour)
From ⇔ To
Description Standard Notes
JAT (1-B9) J15 (1-B9) EN1 encoder + V + 12 V
COLORI COLOURS FARBEN COULEURS COLORES
C arancio orange orange orange naranja
A azzurro blue blau bleu azul
B bianco white weiß blanc blanco
L blu dark blue dunkelblau bleu marine azul intenso
G giallo yellow gelb jaune amarillo
H grigio grey grau gris gris
M marrone brown braun marron castaño
N nero black schwarz noir negro
S rosa pink pink rose rosa
R rosso red rot rouge rojo
V verde green grün vert verde
Z viola/porpora purple violett violet púrpura
Starting connector
Arriving connector
Connector n.
Connector pin n.
Colour
Value of the
measurement
