CESAB B 200 User Manual

2-12
JSOLL (7) --- Unused
JSOLL (8) --- Negative micro GND
JBRA (1) --- +V Pot 5V
JBRA (2) --- Pot slide 0-5V
JBRA (3) --- Unused
JBRA (4) --- Negative potentiometer GND
JBRA (5) --- Microswitch 5V
JBRA (6) --- Microswitch 5V
JBRA (7) --- Unused
JBRA (8) --- Negative micro GND
JTRA (1) --- +V Pot 5V
JTRA (2) --- Pot slide 0-5V
JTRA (3) --- Unused
JTRA (4) --- Negative potentiometer GND
JTRA (5) --- Microswitch 5V
JTRA (6) --- Microswitch 5V
JTRA (7) --- Unused
JTRA (8) --- Negative micro GND
JIV (1) --- +V Pot 5V
JIV (2) --- Pot slide 0-5V
JIV (3) --- Unused
JIV (4) --- Negative potentiometer GND
JIV (5) --- Microswitch 5V
JIV (6) --- Microswitch 5V
JIV (7) --- Unused
JIV (8) --- Negative micro GND
JV (1) --- +V Pot 5V
JV (2) --- Pot slide 0-5V
JV (3) --- Unused
JV (4) --- Negative potentiometer GND
JV (5) --- Microswitch 5V
JV (6) --- Microswitch 5V
JV (7) --- Unused
JV (8) --- Negative micro GND
CN (pin-colour) ⇔ CN (pin-colour)
From ⇔ To
Description Standard Notes
