CESAB B 200 - Page 66

2-14
JCM (1-GN) J107 (2-GN) solenoid valve negative output EVP1 GND
JCM (2-G)
J107 (1-G)
J108 (1-G)
Output +V solenoid valve EVP1 and EV2 +24V
JCM (3-BG) J108 (2-BG) Solenoid valve negative output EV2 GND
JCM (4-BM) J109 (2-BM) Solenoid valve negative output EV3 GND
JCM (5-M)
J109 (1-M)
J110 (1-M)
Output +V solenoid valve EV3 and EV4 +24V
JCM (6-MN) J110 (2-MN) Solenoid valve negative output EV4 GND
JCM (7-ZN) J111 (2-ZN) Solenoid valve negative output EV5 GND
JCM (8-Z)
J111 (1-Z)
J112 (1-Z)
Output +V solenoid valve EV5 and EV6 +24V
JCM (9) ---
5th way solenoid valve negative output
(ON/OFF valve)
GND
JCM (10) --- Unused
JCM (11) --- Unused
JCM (12-BV) J113 (2-BV) Solenoid valve negative output EV7 GND
JCM (13-V)
J113 (1-V)
J114 (1-V)
Output +V solenoid valve EV7 and EV8 +24V
JCM (14-NV) J114 (2-NV) Solenoid valve negative output EV8 GND
JCM (15-BZ) J112 (2-BZ) Solenoid valve negative output EV6 GND
JCM (16) ---
Output +V 5th way solenoid valve
(ON / OFF valve)
+24V
JCM (17)
JCM (18)
JCM (19-BC) J117 (2-BC) Solenoid valve negative output EVP GND
JCM (20-C) J117 (1-C) Output + V solenoid valve EVP +24V
JCM (21)
JCM (22)
JCM (23-N) J1 (-) Negative input GND
CN (pin-colour) ⇔ CN (pin-colour)
From ⇔ To
Description Standard Notes
