CESAB B 215 - Page 109

3-253-25
6 - ANGLE THRESHOLD
7 - MAX SPEED FW
8 - MAX SPEED BW
9 - T ACC DELAY
DESCRIPTION MIN. MAX STEP UNIT
Determines the steering angle from where the speed reduction starts
on a bend, set by the parameter T CURVE CUTBACK
1°a
DESCRIPTION MIN. MAX STEP UNIT
Determines the maximum forward speed 40 135 5 Hz
km/h = (Hz x 30) / 320
DESCRIPTION MIN. MAX STEP UNIT
Determines the maximum backward speed 40 135 5 Hz
km/h = (Hz x 30) / 320
DESCRIPTION MIN. MAX STEP UNIT
Determines the acceleration ramp. 5.5 17.5 0.5 Sec
Minimum setting = maximum acceleration
Maximum setting = minimum acceleration
°a
Steering angle (°a)
ANGLE THRESHOLD
T CURVE CUTBACK
Speed (%)
SPEED REDUCTION RAMP IN CURVE
