E
TRACTION FUNCTION
Views the traction system values
Re
f.
Parameter Description Notes
1
SPEED SET Theoretical speed requested to the drive motor Hz
MOT SPEED Drive motor encoder frequency Hz
2
MOT SLEEP Speed difference between the rotating field and the driving shaft Hz
MOT SPEED Drive motor encoder frequency Hz
3 TRACTION POT Accelerator potentiometer signal voltage V
4 SERVICE BRK Service brake microswitch status ON-OFF
5 SEAT Seat microswitch status ON-OFF
6
FORWARD Forward direction signal ON-OFF
NOT FW No forward direction signal ON-OFF
7
BACKWARD Reverse direction signal ON-OFF
NOT BW No reverse direction signal ON-OFF
8
ENABLE Direction consent signal ON-OFF
NOT EN No direction consent signal ON-OFF
9CFG Accelerator foot board configuration PEDAL
10 PARKING BRAKE Parking brake microswitch status ON-OFF
11
MOTOR TEMP Drive motor temperature °C
CONTR TEMP Traction logic unit temperature °C
12 MOTOR VOLTAGE
Voltage applied to the motor by the logic unit
Expressed as a percentage of the maximum applicable
%
13 BATT VOLTAGE Voltage present on pin 1 connector JT on the logic unit V
14 CAP VOLTAGE Voltage present on power positive (+B) V
15 DHU ENABLE DHU system enabled ON-OFF
