8 SET STEER LEFT
Steering potentiometer acquisition in left limit switch
position (steering wheels turned fully to the left)
The steering potenti-
ometer acquisition
must be repeated
whenever the traction
logic unit or potentiom-
eter is replaced.
If the display does not
memorize the acquisi-
tion data, repeat the
SERIAL NUMBER
acquisition and then
repeat all the other
acquisitions
Re
f.
Function
Description Notes
LEARNING
SET STEER LEFT
SET STEER LEFT
OK
To enter the menu and
start acquisition
OK
To end acquisition
LEARN
SET STEER LEFT
SUCCESSFUL
OUT
To return to the first screen
To place the steering wheels
PLEASE TURN THE
WHEELS TO LEFT
THEN PRESS OK
MATCH X.XX V
fully to the left
