With the balanced pedal the hydraulic oil filter is on the
left side of the tank (see drawing)
Point Operations
[Point 1]
Two different procedures can be followed to remove the
hydraulic oil from the tank:
1. Remove the drain plug under the tank
2. Remove the oil filter cartridge and then use a pump in
order to drain out the hydraulic oil
