CESAB B 215 User Manual

2-9
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
J34 (16-BM) J35 (4-BM) Horn button signal input 5V
GND with
micro closed
J34 (17) --- Unused
J34 (18-BN) J33 (9-BN)
double pedal system reverse micro input
double
5V
GND with
micro closed
J34 (19-RN)
J35 (3-RN)
J33 (8-RN)
J48 (10-RN)
reverse consent signal input 5V
GND with
micro closed
J34 (20-BH) J33 (3-BH)
double pedal system forward micro input
double
5V
GND with
micro closed
J34 (21-HG) --- CAN-BUS LOW
J34 (22-HG) --- CAN-BUS LOW
J34 (23-HG) --- CAN-BUS LOW
J34 (24-R07)
J50 (5-R07)
J50 (6-R07)
Auxiliary power input +Vb
J34 (25-LG) J33 (5-LG) Double foot board configuration input 5V
GND with
micro closed
J34 (26) --- Unused
J34 (27) --- Unused
J34 (28) --- Unused
J34 (29) --- Unused
J34 (30-RH)
J35 (2-RH)
J33 (2-RH)
J48 (5-RH)
reverse consent signal input 5V
GND with
micro closed
J34 (31-LS) J33 (12-LG) Single foot board micro input 5V
GND with
micro closed
J34 (32-RV) J33 (11-RV) Single foot board micro input 5V
GND with
micro closed
J34 (33-AN) --- CAN-BUS HIGH
J34 (34-AN) --- CAN-BUS HIGH
J34 (35-AN) --- CAN-BUS HIGH
J40 (1-MG) J48 (12-MG) Lifting micro signal input 5V
GND with
micro closed
J40 (2) --- Unused
J40 (3-HM) J48 (3-HM) Sideshift micro signal input 5V
GND with
micro closed
J40 (4-AB) J48 (4-AB) 4th way signal input 5V
GND with
micro closed
J40 (5) --- Unused
J40 (6-L) --- Negative input GND
J40 (7-AG) J48 (7-AG) Output + V lifting potentiometer 5V
J40 (8-HG) --- CAN-BUS LOW
J40 (9-HN) J48 (9-HN) Lifting potentiometer negative ouptut GND
J40 (10-AR) J48 (2-AR) Tilting micro signal input 5V
GND with
micro closed
CN (pin-colour) ⇔ CN (pin-colour)
From ⇔ To
Description Standard Notes
