CESAB B 215 User Manual

2-10
J40 (11-V) J48 (11-V) Potentiometer cursor input lifting 0 - 5V
J40 (12) --- Unused
J40 (13) --- Unused
J40 (14) --- Unused
J40 (15-AN) --- CAN-BUS HIGH
J40 (16-GR) J23 (3-GR) Output +V Tilt lock solenoid valve +Vb
J40 (17-N) --- negative input GND
J40 (18) --- Unused
J40 (19-BC) J23 (1-BC) Output +V lower lock solenoid valve +Vb
J40 (20-R07)
J50 (5-R07)
J50 (6-R07)
Auxiliary power input +Vb
J40 (21-R07)
J50 (5-R07)
J50 (6-R07)
Auxiliary power input +Vb
J40 (22) --- Unused
J40 (23) --- Unused
CN (pin-colour) ⇔ CN (pin-colour)
From ⇔ To
Description Standard Notes
