MODEL
188
&
T188
SERIES
SERVICE
MANUAL
11B-8.
ENGINE
DATA
(Cont);
Fuel
Metering
System
Continental
Fuel
Injection
Unmetered
Fuel
Pressure
5.5
to
6.5
PSI
at 600
RPM
33.
5 to
37.5
PSI
at
2700
RPM
Nozzle
Pressure
4.0
to
4.5
PSI
at
600
RPM
16.5
to
18.0
PSI
at 2700
RPM
Fuel
Aviation
100LL/100
Grade
Grade
Minimum
(115/145
Aviation
Grade
with
Lead
Content
limited
to
4. 6cc
Tetraethyl
Lead
per
gallon).
Alternator
28Vdc,
60
Amp
Starter
24
Vdc,
Automatic
engagement
Oil
Capacity
13
U.S.
Quarts
Tachometer
Mechanical
Drive
Oil
Pressure
(PSI)
Normal
30
-
60
Minimum
Idling
10
Maximum
Cold
100
Source
Between
No.
2 and
No.
4
Cylinder
bases
from
left
main
oil
galley.
Oil
Temperature
Normal
Within
Green
Arc
Maximum
Red
Line
(240'F)
Probe
Location
Below
oil
cooler
adaptor
plate
Cylinder
Head Temperature
Normal
Within
Green
Arc
Maximum
Red
Line
(460*F)
Thermocouple
Location
Number
2 cylinder
head
Direction
of Rotation
Clockwise
(Viewed
from
Rear)
Dry
Weight
-
With
Accessories
473.
7 LB
Approximate
SHOP
NOTES:
