MAINTENANCE
175
Anti-lock Braking System (ABS)
ABS is a safety system that prevents locking of the wheels when
driving straight ahead without the inuence of lateral forces.
With the assistance of ABS when fully braking or braking in gritty,
ponding, sliding or other low-adhesive force road conditions, the
vehicle will handle with full brake force and will not lock the wheels,
which could cause an accident�
DANGER
It is not always possible to prevent vehicle rollover in extreme
riding situations, e�g� luggage/cargo loaded with a high center
of gravity, varying road surfaces, steep descents, full braking
without the clutch released� Adapt your riding style to the road
conditions and your driving ability�
ABS operates with two independent brake circuits (front and rear
brakes) � When the brake electronics control unit detects a locking
tendency in a wheel, ABS begins regulating the brake pressure�
Operators will feel the regulating process as a slight pulsing of the
hand or foot brake levers�
When turning on the ignition switch, the ABS indicator should light
up and go out after driving has started� If the ABS indicator does not
go out after driving has started, or if it lights up during driving, this
indicates that there is a fault in the ABS system� If a fault occurs,
ABS will not work, and the wheels may lock during heavy braking�
The brake system stays fully functional, but ABS is not available to
correct potential wheel lock-up�
ABS
Front brake disc
Front wheel
speed sensor
Front left caliper
Front right
caliper
Front master
cylinder brake
reservoir
Rear master
cylinder brake
reservoir
ABS control unit
Rear caliper
Rear wheel
speed sensor
Rear brake disc
