CF MOTO 800MT - Page 206

206
SPECIFICATIONS
Connecting bolt, engine bracket and
frame
Bolt M8*50 28N•m (thread locker 243)
Upper bolt, front footrest Bolt M12*60 100N•m
Bolt, rear shock asborber
Shock absorber bolt (lower
or upper) M12*60
80N•m (thread locker 243)
Nut, output shaft
Small sprocket output
shaft lock nut
102N•m (thread locker 243)
Bolt, frame
Frame upper lock bolt
M10*22
60N•m (thread locker 2701)
Bolt, frame
Frame lower lock bolt
M10*37
60N•m (thread locker 2701)
Handlebar seat
Inner hex screw
M10*1�25*60
45N•m (thread locker 243)
Front brake master cylinder Screw 2N•m
RH handlebar switch Screw 2N•m
E-throttle Screw 2N•m
Clutch lever assy Screw 2N•m
LH handlebar switch Screw 2N•m
LH hand grip assy Screw 2N•m
Steering stem Lock screw M25*1�5 21N•m
Front brake master cylinder pipe Banjo bolt
Ⅱ
25N•m
Front shock absorber, lower triple
clamp
Screw M8*30
Upper 20N•m (thread locker 243)
Lower 16N•m (thread locker 243)
