Chapter 2
Cylinder and Components
Edition 1 – December 2019 SAFETY FIRST 23
MSA G1 Electronic Breathing Apparatus
Swivel height adjustable lumber support
A height adjustable lumbar support provides three easily adjusted operator positions for
ideal comfort and correct fit. The swivel feature allows the harness and carrier frame to
move with the operator. The lumber support is tightened with two adjustable double pull
forward straps.
The lumber support height can be adjusted with one hand whilst being
worn.
Waist belt
The waist belt features a quick release buckle mechanism that sits against the
operator’s body to prevent inadvertent release of the waist belt.
Figure 11: quick release buckle – open Figure 12: quick release buckle – closed
Attachment points
There are three attachment points on the MSA G1 E:
a spring clip below the left shoulder strap adjustment buckle;
an attachment ring below the right shoulder strap adjustment buckle; and
an attachment ring next to the right waist adjustment buckle.
The spring clip on the left should strap serves as an attachment point for the BA tally
tag and/or the facemask.
The spring clip on the left should strap serves as the attachment point for
the tally tag and can be used as an attachment point for the facemask.
