-19-
5.4.1.2 Wall Mounting
For wall mounting, the battery Series
connection number should be less than
4, if more batteries need to be installed,
a cabinet is recommended.
If the battery is connected in the Series mode, it is better for the
Power cable resistance difference between stack and battery pack,
which will have a fade effect on voltage balance, to be installed in the
Ground installation method.
5.4.2 Cable Connection for Parallel Connection
5.4.2.1 Ground Installation
For Parallel installation, please pay
attention to the Cable connection, and
the DIP8 of SW2 will not need to be
changed and stayed on the Initial
Factory State.
