CFE CFE-5100 - Product Components and Indicators

-5-
Battery Protection
Over-Current/Over-Voltage/Short Circuit/
Under-Voltage/Over-Temperature
Safety Certificate
CE & TUV (IEC 62619, IEC 62040) UL1973
Hazard Class of Dangerous Goods
9
Transportation
UN38.3
 Testing Conditions Based on Temperature 25℃ at the Beginning of Life.
 Total Energy/Usable Energy Measured under Specific Conditions of CFE 0.2C CC/CV.
2.2 Exploded View of the Product
2.3 Indicators and Ports
There are two LED indicators on the front of the battery to show its operating status.
Table 2-1 Designations on the battery
