Emotron VS Series Quick Start Guide
- 141 -
L1.28
User-defined Display
Parameter 28
Range:00.00～49.99
Default:00.00
L1.29
User-defined Display
Parameter 29
Range:00.00～49.99
Default:00.00
This function code is for user to customize parameter
User can select any function code of VSS into L1 group, for easy check and change.
L1 group has total 30 customized parameters, if L1 display 00.00, indicating function code is
empty.
The two bit in left indicate function code group, the two bit in right indicate the position in the group.
For example, 05.15 means C1.15. A0~F20 group equal to the two bit in left, U0~U1 equal 48 and 49.
Setting 21~47 indicate the function code is empty.
L1 group parameter
Function code group
00
A0
01
b0
02
b1
03
b2
04
C0
05
C1
06
C2
07
C3
08
d0
09
d1
10
d2
11
d3
12
d4
13
d5
14
E0
15
F0
16
F1
17
F2
18
F3
19
H0
20
L0
21
L1
22
C4
23
F4
47
y0
48
U0
49
U1
