CG VSR48009 - Page 27

Emotron VS Series Quick Start Guide
- 26 -
3.5.2 VSR(4~7.5kW) , VSX(4~22kW) wiring diagram
L1
L2
L3
COM
DI1
DI2
DI3
DI4
DI5
DI6
+10V
AI1
AI2
GND
PE
U
V
W
485+
485-
GND
R1A
R1B
R1C
MCCB
Switch input 1
Switch input 2
Switch input 3
Switch input 4
Switch input 5
1kΩ～5kΩ
DC 0～10V or
0～20mA
M
RS485
Communication
AI1
V
I
(-) (+) PB
Braking resistor
Y2/HO
Open collector output 2
Relay output 1
250V AC/3A
30V DC1A
PLC
Short circuit piece
DI7/HI
+24V
Switch input 6
High-speed
pulse input HI
AI3
1kΩ～5kΩ
DC -10～10V
-10V
AO1
GND
Analog Output 1
0～10V/
0～20mA(VSX)
+24V
Y1
Open collector output 1
AO2
GND
Analog Output 2
0～10V/0～20mA
R2A
R2B
R2C
Relay output 2
250V AC/3A
30V DC/1A
AI2
V
I
AO1
V
I
AO2
V
I
485
ON
OFF
DC 0～10V or
0～20mA(VSX)
50/60Hz
Three-phase 415V
VSX (4~22kW)
VSR (4~7.5kW)
Fig 3-8 VSX(4~22kW) , VSR(4~7.5kW) wiring diagram
