6 Specications
Output power
Stereo and Bi-amplication mode 2×300W
RMS
/ 8Ω, 2×550W
RMS
/ 4Ω, 2×900W
RMS
/ 2Ω
Monaural mode 1×600W
RMS
/ 4Ω, 1×1’000W
RMS
/ 2Ω, 1×1’600W
RMS
/ 1Ω
Bridged mode 1×1’100W
RMS
/ 8Ω, 1×1’700W
RMS
/ 4Ω, 1×2’500W
RMS
/ 2Ω
Analog inputs
Balanced 1x XLR (Vin = 3.6V
RMS
, Zin = 94kΩ or 600Ω; pin1 = GND, pin2 = +, pin3 = -)
Single-ended 1x RCA + 1x BNC (Vin = 1.8VRMS, Zin = 47kΩ or 300Ω)
Amplication
Input stage Ultra low noise, high slew rate, zero global feedback,
full discrete class A design
Output stage Ultra low noise, high slew rate, with adjustable feedback,
full discrete class AB design
Feedback Unique user programmable amplier stage local/global feedback ratio
in 1% steps
Gain +18dB to +24dB, in 0.5dB steps (stereo, monaural and bi-amp modes)
+24dB to +30dB, in 0.5dB steps (bridged mode)
Analog Audio outputs
Speaker terminals 4 pairs of customized Argento Audio binding posts
Total Harmonic Distortion + Noise Less than 0.01% at 0% global feedback (100% local feedback)
(THD+N) Less than 0.002% at 100% global feedback (0% local feedback)
(1kHz signal, BW 22Hz-80kHz window, 50W
RMS
under 8Ω,
all operating modes)
Inter-modulation distortion Less than 0.001%
(IMD SMPTE)
Signal to Noise Ratio Better than 132dB, stereo, monaural and bi-amp modes
(SNR, unweighted) Better than 135dB, bridged mode
Bandwidth DC to 500kHz (low pass lter off)
(-3dB point, 1W
RMS
into 8Ω) DC to 120kHz (low pass lter on)
Output noise (27Ω input terminated, Less than -95dBu (14 μV
RMS
), stereo, bi-amp and monaural modes
22Hz-22kHz measurement window) Less than -92dBu (20 μV
RMS
), bridged mode
General
Display 800×480 24bits RGB
Power supply Selectable 100V, 115V or 230V AC, 47Hz to 63Hz, <1W in Standby
Dimensions of each chassis (WxDxH) 440mm x 500mm x 272mm (main body)
440mm x 560mm x 285mm (overall, including connectors and feet)
Weight Audio unit: 53kg
Power supply unit: 78 kg
Software update USB port for software update / Ethernet based system control
M10 User Manual 26
