104
GB
MENU
SUB-MENU
PARAMETER
DESCRIPTION RANGE NOTE
6 4 Z3 Zone Module Settings
6 4 0 Zone pump modulation
0. Fixed
1. Modulating on DeltaT
2. Modulating on Pressure
641Target deltaT for pump modulation
6 4 2 Pump fi xed speed
7 ZONE MODULE
7 1 Manual mode
7 1 0 ZM Manual mode activation ON - OFF
7 1 1 Z1 pump control ON - OFF
7 1 2 Z2 pump control ON - OFF
7 1 3 Z3 pump control ON - OFF
7 1 4 Z2 mix valve control
0. OFF
1. Open
2. Closed
7 1 5 Z3 mix valve control
0. OFF
1. Open
2. Closed
7 2 General Zone Module
7 2 0 Hydraulic scheme defi nition
0. Not defi ned
1. MCD
2. MGM II
3. MGM III
4. MGZ I
5. MGZ II
6. MGZ III
721FlowT Offset
7 2 2 Auxiliary output setting
0. Heat request
1. External pump
2. Alarm
7 2 3 External temperature correction
menu - settings
