CHAFFOTEAUX EXPERT CONTROL - Page 112

112
GB
MENU SUB-MENU PARAMETER
DESCRIPTION RANGE NOTE
10 3 Fresh Water Station Diagnostic
10 3 0 DHW Out temperature
10 3 1 DHW In temperature
10 3 2 CH Out temperature
10 3 3 CH In temperature
10 3 4 DHW Flow Rate
10 3 5 NTC Storage Low
10 3 6 DHW Consumption Total
10 3 7 Loading Pump Run Time
11 Multifunctional PCB
11 0 General
11 0 0 Function selection
0. Not defi ned
1. 3 direct zones
2. Lockout and reset manager
3. Generic differential
thermostat
4. Generic thermostat
5. Time programmed output
11 0 1 Manual mode activation ON - OFF
11 0 2 OUT1 control ON - OFF
11 0 3 OUT2 control ON - OFF
11 0 4 OUT3 control ON - OFF
11 1 Diagnostics
11 1 0 IN1 temperature
11 1 1 IN2 temperature
11 1 2 IN3 temperature
11 1 3 OUT1 status
menu - settings
