79032966 A Rev. 01-9
Safety
REAR HOOK
FIG. 29: The rear hook (1) is located in the center of the
combine on the rear axle.
Use the rear hook (1) as a point on the combine to fasten
a suitable chain to aid in pulling the combine out of the
mud when the combine is stuck and not able to drive out.
• Do not go past the breaking strength of the chain.
• Do not use ropes or tow straps.
• Do not use the hook to pull a trailer.
• Do not use the hook to transport the combine on the
road.
m
WARNING: Do not use a rope or strap to
pull the combine out of the mud. Energy
stored in these devices can cause serious
personal injury if the device should break.
TRAVEL ON PUBLIC ROADS
FIG. 30: Consult your local law enforcement agency for
local regulations regarding movement of farm equipment
on public roads.
Use headlights, flashing warning lights, taillights and turn
signals, day and night, unless prohibited by local law.
Make sure lights, reflectors and SMV emblem are
installed, in good condition and wiped clean.
Lock brake pedals together with the locking strap so that
both front wheel brakes will be applied simultaneously.
Be aware of other traffic on the road. Keep well over to
your own side of the road and pull over, whenever
possible, to let faster traffic pass.
Adjust travel speed to maintain control at all times. Never
allow combine to coast down hills.
FIG. 29
1
K512094
FIG. 30
S-1025
