GENERAL INFORMATION
MACHINE MAIN COMPONENTS
Some of the main components of the combine are as
follows:
1. Feeder
2. Operator Cab
3. Roof Lamps
4. Rear View Mirrors
5. Beacon Lamp
6. Grain Tank Loading Auger
7. Grain Tank
8. Engine Compartment
9. Grain Tank Unloading Auger
10. Straw Chopper
11. Steering Axle
12. Drive Axle
13. Operator Platform Ladder
14. Operator Platform
15. Single Point Header Connection
