79032966 A Rev. 01-39
General Information
FIG. 80: Remove the centrifugal filter (1) cover by
loosening the retainer on top of the cover.
Remove the filter canister (2) and the seal ring (3) from
the centrifugal filter head (4).
Using clean engine lubricating oil, lightly oil the seal ring
and install the ring on the filter head.
Install new filter canister on the filter head.
Install the centrifugal cover on the filter head.
FIG. 81: Clean around filter head (1), unscrew filter
element (2) and discard. Check that threaded adapter is
secure in filter head and clean gasket surface in head.
Prime the new element with clean engine lubricating oil by
pouring oil slowly into central threaded orifice, allowing
time for oil to fill bowl through filter element.
Using clean engine lubricating oil, lightly oil top seal of
replacement element.
Screw replacement element into filter head until element
seal just touches head and then tighten by hand one half
turn.
FIG. 82: Remove the filler cap (1) and fill crankcase
through filler cap hole in valve cover to correct level with
recommended oil.
Run engine and check for leaks.
IMPORTANT: Do not run engine above idling speed until
oil pressure has built up.
Check oil level after running engine and add as required
to bring oil to correct level.
FIG. 80
d-10626
1
2
3
4
FIG. 81
1
2
L601563
FIG. 82
1
N722142
