CAPXS Overview
Smart Video Intercom S (Model CAPXS) is a cloud based access control solution
that includes an integrated video camera enabling advanced video features.
DISPLAY (TOUCHSCREEN)
MICROPHONE
TERMINALS
SPEAKER
POWER
RESET BUTTON
ETHERNET CONNECTION
CAMERA WINDOW
POSTAL LOCK
SWITCH
N. O.
COM
WIEGAND
BLACK
GND
GREEN
DATA 0
WHITE
DATA 1
REX
GND
SUP
PRI. RLY.
N. O.
COM
N. C.
AUX. RLY.
N. O.
COM
N. C.
RESETPOWER ETHERNET
