APPENDIX
FEATURE PRIMARY OPERATOR SECONDARY OPERATOR
Timer-to-
Close
Set the TTC dial to desired
setting
OFF
Bi-Part Delay
Switch
Bi-Part Delay: ON (will
open last and close first)
Tandem Mode: OFF
Synchronized Close: ON
Bi-Part Delay: OFF (will
open first and close last)
Tandem Mode: OFF
Synchronized Close: ON
DUAL GATE SETTINGS
NOTE: We recommend that all accessories and board configurations are set on the primary operator.
MAIN CONTROL BOARD
ACCESSORY PRIMARY OPERATOR SECONDARY OPERATOR
Remote Controls Program remote
controls 1 to 50 to the
primary operator.
Program remote controls
51 to 100 to the
secondary operator
LiftMaster
Internet Gateway
Program to primary
operator.
Garage and Gate
Monitor
Program to primary
operator.
