Chamberlain RSL12VDC - Operator Specifications

6
OPERATOR SPECIFICATIONS
This model is intended for use in vehicular slide gate applications:
INTRODUCTION
10-1/2"
20-3/8"
15-3/16"
Usage Classification
Class I & II
Main AC Supply
120 Vac, .5 Amps (6.5 Amps including Accessory Outlets)
System Operating Voltage
12 Vdc Battery Run / Battery Backup
Accessory Power
12 Vdc, 500mA max. for ON + SW (switched)
Solar Power Max
12 Vdc at 30 watts max.
Maximum Gate Weight
800 lbs (363.6 kg)
Maximum Gate Travel Distance
25 feet (7.62 m)
Maximum Gate Travel Speed
10 inches/second
Maximum Daily Cycle Rate
120 cycles/day
Maximum Duty Cycle
Continuous
Operating Temperature
Without Heater: -20°C to 60°C (-4°F to 140°F)
With Optional Heater: -40°C to 60°C (-40°F to 140°F)
Expansion Board
Optional
Inherent Entrapment Protection (Type A)
Dual - RPM and Current Sense
External Entrapment Protection (Type B1 and/or Type B2)
3 inputs on main board - 3 photoelectric sensors and up to 2 edge sensors
13.65"
MOUNTING FOOTPRINT
7.49"
.63"
